High Efficiency Three Levels Fertilizer Pellets Ball Shaping Machine
Introduction to fertilizer ball shaping machine
The organic fertilizer round polishing machine is designed on the basis of flat die extrusion granulator machine. It's used to polish the cylindrical pellets made by flat die pelleting machine to ball shape granules one time
Specifications of fertilizer ball shaping machine
| Model | Diameter | Power(kw) | Capacity(t/h) |
| PYS800-1 | 800mm | 5.5 | 1-3 |
| PYS800-2 | 800mm | 11 | 1-3 |
| PYS1000-1 | 1000mm | 5.5 | 2-4 |
| PYS1000-2 | 1000mm | 11 | 2-4 |
| PYS1000-3 | 1000mm | 16.5 | 2-4 |
| PYS1200-1 | 1200mm | 7.5 | 3-6 |
| PYS1200-2 | 1200mm | 15 | 3-6 |
| PYS1500-2 | 1200mm | 30 | 4-8 |
Working principle of fertilizer ball shaping machine
The cylindrical particles made by the flat die granulator will be transformed into the Polishing Machine before they are hardened. Under the influences of the centrifugal forces, the cylindrical particles will be turned into the spherical ones rapidly. With the additional function of drying, it can help leave out the organic fertilizer drying process, which will reduce the production expenses and provide a more efficient and economic way for customers.
Features of fertilizer ball shaping machine
1. This machine is with nice looking, simple structure, safe and reliable.
2. Easy operation and maintenance. It can be used to operate according to the instructions.
3. Good anti-overload ability, able to adapt to different environment.
4. Power consumption is small, low production costs, high economic efficiency.
Advantages of fertilizer ball shaping machine
1. The machine is made up by two or more polishing cylinder orderly, the material will be out after several times polishing, finished grain size, consistent densities, and roundness of the smooth, high finished products rate.
2. This machine works under low temperature and pressure, so the activity of the organic fertilizer will not be affected.
3. It is widely used for polishing all kinds of organic fertilizer granules, of which the quality can be ensured.
Applications of fertilizer ball shaping machine
The fertilizer ball shaping machine is mainly used for polishing organic fertilizer. And the raw materials for organic fertilizer production can be diverse.
1. Agricultural Waste: straws, mushroom residues, bio-gas residues etc.
2. Industrial Waste: vinegar residues, sugar residues, lees etc.
3. Animal Manure: chicken manure, cow manure, horse manure etc.
4. Household Garbage: kitchen waste, food waste, restaurant garbage etc.
FAQ
Do you provide installation service after ordering your machines?
As for the single machine, we provide the users instruction and operation video.
As for the production line,we provide the professional construction drawing,and arrange the engineer to guide the user install the machines and help to train the workers.
|
|
High Efficiency Three Levels Fertilizer Pellets Ball Shaping Machine Images
|
